NC750X

Description

Engine and Performance

• Engine Type: Liquid-cooled 4-stroke 8-valve, SOHC parallel 2-cylinder
• Displacement: 745 cc
• Max. Power Output: 43.1 kW @ 6,750 rpm (58 hp)
• Max. Torque: 69 Nm @ 4,750 rpm
• Fuel Consumption: 3.6 L/100 km (WMTC Mode)
• Bore X Stroke: 77 mm x 80 mm
• Compression Ratio: 10.7:1
• Drive Type: Chain
• Clutch Type: Wet multiplate clutch (MT); Dual Wet multiplate hydraulic (DCT)
• Transmission Type: 6-speed Manual or 6-speed Dual Clutch Transmission (DCT)
• A2 License Version: Available (35 kW @ 6,000 rpm)

Chassis, Suspension, and Brakes

• Frame Type: Diamond; steel pipe
• Front Suspension: 41mm telescopic fork, 120mm travel
• Rear Suspension: Monoshock damper, Pro-Link swingarm, 120mm travel
• Front Brake: Dual axial mounted two-piston brake calipers, 296 mm floating double discs
• Rear Brake: Single-piston caliper, 240 mm single disc
• ABS System: Dual-channel ABS
• Front Tyre: 120/70-ZR17 M/C
• Rear Tyre: 160/60-ZR17 M/C
• Wheels: Lightweight "3by3" cast aluminium 17-inch

Dimensions and Weights

• Length x Width x Height: 2210 mm x 846 mm x 1330 mm
• Wheelbase: 1525 mm (MT), 1530 mm (DCT)
• Ground Clearance: 145 mm
• Seat Height: 802 mm
• Kerb Weight: 216 kg (MT), 226 kg (DCT)
• Fuel Tank Capacity: 14.1 Litres

Key Features and Technology (2025 Model Updates)

• Storage: 23-litre storage compartment where the fuel tank is usually located
• Instruments: 5-inch TFT display with Honda RoadSync smartphone connectivity
• Lighting: Full LED lights with refreshed LED headlight
• Riding Modes: Throttle By Wire with 3 default modes (Standard, Sport, Rain) + USER customization
• Traction Control: 3-Level Honda Selectable Torque Control (HSTC) + OFF
• Safety: Emergency Stop Signal (ESS)
• Sustainability: Use of coloured Durabio™ material for bodywork
• DCT Update (2025): Improved low-speed handling (10 km/h and under) to make U-turns and maneuvering easier
